500*1000mm 12V Silicone Heating Element For Electronic Devices

Jiangyin Huilong Electric Heating Appliance Co., Ltd
Contact Now

500*1000mm 12V Silicone Heating Element For Electronic Devices

Place of Origin : JiangSu

Brand Name : Hotlong

Certification : ISO9001,UL,CE

MOQ : 50-100

Price : consultative

Delivery Time : 7-10

Power source : Electric

Voltage : 12-480v

Condition : New

Dimension(l*w*h) : Custom Size

Warranty : 12 Months

Shape : square

Contact Now

Silicone Heating Element

Technical Data:

1. Temperature range: -40.00~250.00°C

2. Electric resistance precision: ±10%( bigger value selected)

3. Power density: 0.10~1.50w/cm²

4. Mechanical pressure: 100.00kg/cm²

5. Minimum bending radius: 3.20mm

Application:

1. Industrial equipment, pipelines, barrels, tanks, etc.

2. Outdoors telecommunication equipment

3. Medical equipment and devices

4. Outdoors electronic devices

5.Thermal imaging of imaging equipment

6. Case protection under cold and moist environment

7. Industrial ovens and thermal processing equipment

8. Ventilator supports

9. Laminating equipment

10. Vessels

Specifications

Power Source: Electric
Voltage: 12-480V
Power : ≤ 3W/cm2
Maximum size: 500mm*1000mm
Thickness:1-1.5mm
Recommended working temperature:≤200℃
Color: Brown
Warranty: 1 Year
Material: silicone rubber with etching film
Insulation material: silicone rubber
Insulation resistance: 1000V,≥100MΩ
Certification: ISO9001, CE, Rohs, UL
Application: as customer’s need

Accessories optional

Name Model Specifications
Leading line PTFE wire UL1332 300V,26AWG-10AWG
PTFE wire UL1330 600V,26AWG-10AWG
PI line 300V,30AWG-20AWG
Silicone rubber line 300V,0.5mm2-2.5mm2
Glass fiber line 300V,0.5mm2-4mm2
3M glue 468/467 working temperature ≤ 149℃
966/9079 working temperature ≤ 179℃
9888T working temperature ≤ 119℃
Controller OT1 0-200°C JPt 100Ω sensor
OT3 0-300°C PID controller
OT4. OT5 100ºC
EGO 0-40ºC 30-110ºC 60-200ºC
Thermo 50ºC 70ºC 100ºC 120ºC 150ºC

Application500*1000mm 12V Silicone Heating Element For Electronic Devices

500*1000mm 12V Silicone Heating Element For Electronic Devices500*1000mm 12V Silicone Heating Element For Electronic Devices500*1000mm 12V Silicone Heating Element For Electronic Devices
